iNCA812-DFR 4MM
iNCA812-DFR 4mm adopts advanced deep learning algorithm and powerful GPU to realize instant
face detection, capture, and comparison to accomplish face recognition and related alarm
triggering. The camera can be widely used in retail industry and security departments, such as
hotel, shopping malls to improve the VIP service, custom, airport to control some key passageway.
• 1/2.8″ Progressive
• Scan CMOS
• 1920 × 1080 @ 30fps
• 120dB WDR
• H.265+, H.265, H.264+, H.264 5 video streams
• Face recognition
• IR range up to 10 m
NC714-IDZ
● 1/1.8” Progressive Scan CMOS
● 2560 × 1440 @ 30fps
● MJPEG up to 1920 × 1080 @ 30fps
● 2.8 to 12 mm/8 to 32 mm motorized lens
● Color: 0.002 Lux @ (F1.2, AGC ON), 0.005 Lux @ (F1.8, AGC ON), 0 Lux with IR
● H.265, H.265+, H.264, H.264+
● 140dB WDR
● IR range: up to 30 m
● Alarm 1 input/1 output, audio 1 input/1 output, RS-485
● IK10
● 5 streams and up to 5 custom streams
● 6 behavior analyses, 3 exception detection, and face detection
● Built-in microSD/SDHC/SDXC card slot, up to 256 GB
● Metadata of intrusion detection, line crossing detection, region entrance
detection, region exiting detection, unattended baggage detection, object
removal, face capture and queue management are supported
iNRA10-32/8F
Features and Functions
Face Detection and Analysis
Powerful face pictures library management
Face pictures comparison and alarm linkage actions
Search by picture supported
More precise face recognition and analytics based on deep learning algorithm
Video Input and Transmission
Up to 32-ch IP camera input
Connectable to the third-party network cameras
HD Video Output and Decoding
Supports H.265+ decoding format
Up to 16-ch decoding at 1080p resolution
HDMI1/VGA1 and HDMI2/VGA2 outputs provided
HDMI1 output at up to 4K (4096 × 2160) resolution
Storage and Playback
Full channel recording at up to 12 MP resolution
Up to 10 TB capacity for each HDD
HDD hot swap with RAID0, RAID1, RAID5, RAID6 and RAID10 storage scheme configurable
16-ch synchronous playback at 1080p resolution
VCA & POS Function
Supports multiple VCA (Video Content Analytics) events
Smart search for the selected area in the video; and smart playback to improve the playback efficiency
Supports VCA search for fire/ship/temperature/temperature difference detection triggered video files
POS information overlay on live view and playback
POS triggered recording and alarm
Professional and Reliable
ANR technology to enhance the storage reliability when the network is disconnected
Configurable normal or hot spare working mode to constitute an N+1 hot spare system
Network & Ethernet Access
Hik-Connect for easy network management
2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
AC604-DAC
AC604-DAC access controller is designed with latest structure with TCP/IP and RS485 communication interface. The communication data is encrypted to improve the security of system. The controller also supports off line operation and is designed with tamper-proof switch.
AC602-DAC
AC602-DAC access controller is designed with latest structure with TCP/IP and RS485 communication interface. The communication data is encrypted to improve the security of system. The controller also supports offline operation and is designed with tamper-proof switch.
AC606S-FRT
Wall mounting
• 5-inch LCD touch screen to display operation interface, etc.
• 2 MP wide-angle lens
• Wide dynamic range (WDR)
• Face recognition distance: 0.3 m to 1 m
• High performance processor with deep learning algorithm
• 3200 face capacity
• Multiple authentication modes
• Accurate and fast face recognition function. The face recognition duration is no more than 1s per person and the face
recognition accuracy rate is more than 99%
• Applies data to the device via TCP/IP or uploading data to the device via the USB flash drive
• Stand-alone operation
• Multiple languages supported: English, Thai, Spanish, and Arabic
• Supported attendance status: check in, check out, break out, break in, overtime in, and overtime out
