IPC-MD254E-IR-S 5MP IR FIXED-FOCAL DOME WIZSENSE

Name: IPC-MD254E-IR-S 5MP IR FIXED-FOCAL DOME WIZSENSE
SKU: IPC-MD254E-IR-S-2.8

SKU: IPC-MD254E-IR-S-2.8

5MP IR FIXED-FOCAL DOME WIZSENSE

11 People watching this product now!

Carrier information

Payment methods

Unlimited help desk

5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.
H.265 codec, high compression rate, ultra-low bit rate.
Built-in IR LED, and the max. illumination distance is 30 m.
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Supports max. 256 G Micro SD card; built in MIC.
12 VDC/PoE power supply, easy for installation.
IP67, IK10 protection.
SMD Plus.

Product Manual

No related firmware found.

Additional information

Camera Style	Dome
Image Sensor	1/2.7" CMOS
Lens Type	Fixed Lens
Max. Resolution	2960 × 1668
ROM/RAM	128 MB/256 MB
Scanning System	Progressive
Shutter Speed	1/3 s to 1/100 , 000 s , Auto/Manual
Minimum Illumination	0.007 Lux@F1.6 (Color, 30 IRE); 0.0007 Lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
Illumination Distance	Up to 30 m (98.43 ft) (IR)
Pan/Tilt/Rotation Range	Pan: 0°–355° ; Tilt: 0°–65°; Rotation: 0°–355°
Video Bit Rate	H.264: 32 kbps–8192 kbps; H.265: 12 kbps–8192 kbps
WDR	120 dB
Digital Noise Reduction	3D DNR
Lens Mount	M12
Focal Length	2.8 mm; 3.6 mm
Max. Aperture	F1.6
Storage	FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Audio	Built-in Mic
Power	12 VDC/PoE (802.3af)
Power Consumption	Basic: 2.3 W (12 VDC); 2.9 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 5 W (12 VDC); 6.1 W (PoE)
Casing Material	Metal
Product Dimensions	81.0 mm × Φ109.9 mm (3.19" × Φ4.33")
Net Weight	0.34 kg (0.75 lb)
Gross Weight	0.49 kg (1.08 lb)
Protection	IK10 , IP67
