XVI-EB152T-DLM 5MP SMART DUAL LIGHT HDCVI FIXED TURRET CAMERA

Name: XVI-EB152T-DLM 5MP SMART DUAL LIGHT HDCVI FIXED TURRET CAMERA
SKU: XVI-EB152T-DLM-2.8

SKU: XVI-EB152T-DLM-2.8

5MP SMART DUAL LIGHT HDCVI FIXED TURRET CAMERA

15 People watching this product now!

Carrier information

Payment methods

Unlimited help desk

Product Manual

No related firmware found.

Additional information

Camera Resolutions	5 MP
Camera Style	Turret
Lens Type	Fixed Lens
Max. Resolution	2880 × 1620
Scanning System	Progressive
Shutter Speed	PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
Minimum Illumination	0.05 lux@F1.6 (Color, 30 IRE); 0.005 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
Illumination Distance	IR: 40 m (131.23 ft); Warm Light: 40 m (131.23 ft)
Angle Adjustment	Pan: 0°–360° ; Tilt: 0°–78°; Rotation: 0°–360°
Lens Mount	M12
Focal Length	2.8mm; 3.6mm
Max. Aperture	F1.6
Field of View	H: 106°; V: 56°; D: 125°;H: 92°; V: 48°; D: 109°
Resolution	5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night	Auto(ICR)/Color/B/W
Digital Noise Reduction	2D DNR
Certifications	CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035; FCC: 47 CFR FCC Part 15, Subpart B; UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio	Built-in Mic
Power	12VDC ±30%
Power Consumption	Max 4.5 W (12 VDC, WLED on)
Casing Material	Metal
Product Dimensions	φ106.0 mm × 93.6 mm (φ4.17" × 3.69"
Net Weight	0.47 kg (1.04 lb
Gross Weight	0.6 kg (1.32 lb)
Protection	IP67
