iNVR538-32-4K 32 CHANNELS 2U 8HDD WIZSENSE NETWORK VIDEO RECORDER

Name: iNVR538-32-4K 32 CHANNELS 2U 8HDD WIZSENSE NETWORK VIDEO RECORDER
SKU: iNVR538-32-4K

SKU: iNVR538-32-4K

32 CHANNELS 2U 8HDD WIZSENSE NETWORK VIDEO RECORDER

Add to wishlist

Add to compare

16 People watching this product now!

Fast Shipping

Carrier information

1k products

Payment methods

24/7 Support

Unlimited help desk

Description

Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
Max. decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps.
Max. 384 Mbps incoming/recording/outgoing bandwidth.
Support AcuPick with Max. 16-Channel.
Support N+M cluster.
Support Raid0/1/5/6/10.
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus.
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
Security baseline 2.3.

Download

Product Manual

iNVR538-32-4K.pdf

No related firmware found.

Additional information

Channels	32 Channel
Main Processor	Industrial-grade processor
Operating System	Embedded Linux
Operation Interface	Web; local GUI
AI by Recorder	Face detection; face recognition; perimeter protection; SMD Plus
AI by Camera	Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
AcuPick AI by Camera + Recorder	Max. 16-channel, 1 combined event per channel/s
Access Channel	32
Resolution	32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Multi-screen Display	Main screen: 1/4/8/9/16/25/36 Sub screen: 1/4/8/9/16
Third-party Camera Access	ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung
Face Attributes	Gender; age group; glasses; expressions; face mask; beard
SMD Plus by Recorder	8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera	16 channels
HDD Support	8 HDD
HDD Interface	8 SATA ports, each disk can contain up to 16 TB. This limit varies depending on the environment temperature.
eSATA/RS-232	45658
RS-485	2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication)
USB	4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
Network Port	2(10/100/1000 Mbps Ethernet port, RJ-45)
Power	100 to 240 VAC
Power Consumption	Total output of NVR is ≤ 13 W (without HDD)
Case	2U
Net Weight	6.4 kg (14.11 lb)
Gross Weight	9.01 kg (19.86 lb)
Product Dimensions	439.9 mm × 457.9 mm x 89.0 mm (17.32" × 18.03" × 3.50")
Packaging Dimensions	570.0 mm × 570.0 mm x 226.0 mm (22.44" × 22.44" × 8.90")
