iXVR531H-8 8 Channel Penta-brid 1080P Mini 1U Digital Video Recorder

Name: iXVR531H-8 8 Channel Penta-brid 1080P Mini 1U Digital Video Recorder
SKU: iXVR531H-8

SKU: iXVR531H-8

8 Channel Penta-brid 1080P Mini 1U Digital Video Recorder

12 People watching this product now!

Carrier information

Payment methods

Unlimited help desk

H.265+/H.265 dual-stream video compression
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 12 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps incoming bandwidth
Up to 2 channels video stream (analog channel) Perimeter Protection
Up to 8 channels video stream (analog channel) SMD Plus
Up to 2 channels video stream (analog channel) human face recognition
IoT & POS functionalities

Product Manual

Title	Description	Download
iXVR531-8	iXVR531-8	XVR531-8_210415

Additional information

Main Processor	Embedded Processor
Operating System	Embedded LINUX
Analog Camera Input	8 Channel , BNC
HDCVI Camera	5MP , 4MP , 1080P@25/30fps , 720P@50/60fps , 720P@25/30fps
AHD Camera	5MP , 4MP , 1080P@25/30 , 720P@25/30fps
IP Camera Input	8+4 channels, each channel up to 6MP
Compression	AI Coding/H.265+/H.265/H.264+/H.264
Channels	8 Channel
Resolution	5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
Bit Rate	32 Kbps–6144 Kbps Per Channel
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Video Detection	Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Playback	1/4/9It changes to 1/4 split when Face or IVS&SMD is selected in AI Mode.
Storage Internal HDD	1 SATA Port, up to 10TB capacity
USB/RS485	USB: 2 USB Ports (USB 2.0) RS485: 1 Port, for PTZ Control
Case	1U
Power	DC12V
Power Consumption (Without HDD)	<7W
Dimensions	Mini 1U, 325 mm × 257 mm × 55 mm (12.80" × 10.10" × 2.17")
Net Weight (without HDD)	1.2 kg (2.7 lb)
Gross Weight	1.9 kg (4.2 lb)
Installation	Desktop installation
Certifications	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
