A2204S500-CMR-UL 500ft 4×22AWG Solid Bare Copper Alarm Cable UL Listed
C5EBC1000UL-CMR Cat5e U/UTP 4 Pair Riser Network Cable | UL, CMR, 24AWG | Bare Copper
| Shielding Type |
Unshielded (U/UTP) |
|---|---|
| Category Type | |
| Jacket Rating | |
| Color |
Black ,Blue ,White ,Yellow |
| Test Standard |
ISO/IEC11801 、TIA-568-C.2 、YD/T1019 |
| Conductor Material |
Solid-Bare copper |
| Insulation Material |
HDPE |
| Sheath Thickness |
0.50±0.05 mm |
| Packing |
Wooden Tray & Carton |
| Carton dimension |
35cm*35cm*20cm |
| Packing length |
(305±1.5)m |
C6BC1000-OD-BK Outdoor Waterblock Cat6 550MHz 1000ft
| Category Type | |
|---|---|
| Shielding Type |
Unshielded (U/UTP) |
| Voltage /temperature |
30V/75℃ |
| Product specifications |
1/0.52mm BC ,PE Jacket ,OUTDOOR，1-550Mhz |
| Conductor |
1/0.52mm BC |
| Insulation material |
HDPE |
| Insulation OD |
0.94mm |
| Insulation color |
blue、white(blue)、orange、white(orange)、green、white(green)、brown、white(brown) |
| Twisted pairs |
blue&white(blue)、orange&white(orange)、green&white(green)、brown&white(brown) |
| Cable assemble |
All of the wires stranded together，filler Cross skeleton，Mylar tape wrapping |
| Jacket material |
PE，filler polypropylene ripcord |
| Jacket OD. |
5.9±0.2mm |
| Test Voltage |
1.5KV DC |
| Conductor resistance |
93.8Ω/km Max. |
| Electrical characteristics |
ANSI/TIA568C.2 CAT6 Channel Spec. |
| Characteristic Impedance |
100±15Ω |
| Transmission frequency |
1-550Mhz |
| Operating voltage |
30V |
| No hazardous substance |
RoHS Compliant Directive 2011/65/EU |
C6BC1000UL-CMP Cat6 U/UTP 4Pair PLENUM Network Cable | UL, CMP, 23AWG | Bare Copper
| Category Type | |
|---|---|
| Shielding Type |
Unshielded (U/UTP) |
| Jacket Rating | |
| Test Standard |
ISO/IEC11801 ,TIA-568-C.2 ,YD/T1019 |
| Conductor Material |
Solid-Bare Copper |
| Insulation Material |
FEP |
| Sheath Thickness |
0.4±0.05 mm |
| Packing |
Wooden Tray & Carton |
| Carton dimension |
40.5*40.5*21 cm OR customized |
| Packing length |
305±1.5m |
| Color |
Black ,White |
C6BC1000UL-CMR 1000 ft U/UTP 4 PAIRS CABLE-CATEGORY 6-250MHZ PVC SHEATH
| Color |
Black ,Blue ,White ,Yellow |
|---|---|
| Shielding Type |
Unshielded (U/UTP) |
| Category Type | |
| Jacket Rating | |
| Test Standard |
ISO/EC11801、TIA-568-C.2、YD/T1019 |
| Conductor Material |
Solid-Bare Copper |
| Conductor Nom.0.D.(mm) |
0.570 uP +0.005 ,down -0.005 |
| Insulation Material |
HDPE |
| Insulation Diameter |
1.02±0.03mm |
| Cross |
4.5*0.45 mm |
| Sheath Thickness |
0.55+0.05 mm |
| Sheath Surface |
Clean,Frap,Satiation |
| Sheath Material |
PVC |
| Packing |
Wooden Tray & Carton |
| Carton dimension |
40.5*40.5*21cm |
| Packing length |
305±1.5m |
CAT5E-CCU-1000 1000ft CAT5E CCU UTP Cable
CAT5E-CCU-1000-WN 1000FT CCU UTP CABLE
CAT6-CCU-1000 1000ft UL Listed 550MHz Full Copper Cat6 Cable
CAT6-PLENUM-CMP-600MHZ UTP PLENUM NETWORK CABLE
CAT6-RISER-CMR-600MHZ 1000ft CAT6 CCU UTP Cable
HD0402-100FT-F 100ft 4K@60Hz 18Gbps High Speed HDMI AOC Fiber Cable
| Cable Length |
100ft |
|---|---|
| Resolution Support |
4K @ 60Hz 2K @ 144Hz 1080P @ 240Hz |
| Color Depth |
Up to 12-bit |
| Jacket Material |
PVC |
| HDMI Version |
HDMI 2.0 |
| Connector Material |
Gold-plated copper shell |
| Conductor Material |
Optical fiber + tin-plated copper |
| Outer Diameter (OD) |
4.2 mm |
| Operating Temperature |
-10°C to 45°C |
| Storage Temperature |
-15°C to 70°C |
